Type
Ducati V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
Displacement
1,158 cc (71 cu in)
Bore and stroke
83 x 53.3 mm
Compression Ratio
14:1
Power
170 hp (125 kW) @ 10,750 rpm
Torque
124 Nm (12,6 kgm) @ 9,000 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 46mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel muffler, double catalytic converter and 6 lambda probes
Gearbox
6 speed with Ducati Quick Shift up/down
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=36/20, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z16; Rear sprocket Z42
Clutch
Multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Ø 50 mm fully adjustable USD mechanical fork, compression and rebound damping manual adjustment
Front wheel
Light alloy cast, 3" x 19"
Front tyre
Pirelli Scorpion Trail II 120/70 ZR 19
Real suspension
Fully adjustable monoshock, Remote spring preload adjustment, aluminium double-sided swingarm
Rear wheel
Light alloy cast, 4.5" x 17"
Rear tyre
Pirelli Scorpion Trail II 170/60 ZR 17
Wheel travel
170 mm / 180 mm (6.7 in / 7.1 in)
Front brake
2 x Ø 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 280 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
5" TFT colour display
Wet weight
229 kg (505 lb)
Seat height
Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in) 870 mm - 890 mm (34.3 in - 35.0 in) with high foam seat accessory 855 mm - 875 mm (33.7 in - 34.4 in) with mid/high foam seat accessory 810 mm - 830 mm (31.9 in - 32.7 in) with low foam seat accessory
Wheelbase
1,566 mm (61.7 in)
Rake
24.2°
Trail
100.6 mm (4.0 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Mode, Power Mode, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Ducati Cornering Light, Vehicle Hold Control, Daytime Running Light*, Ducati Brake Light EVO
Standard equipment
Ducati Quick Shift, Cruise control, Backlit handlebar switches, 5" TFT colour display, Full LED headlight
Warranty
24 months (48 months**), unlimited mileage
Valve clearance check desmo
15,000 km (9,000 miles) / 24 months
Valve clearance check
60,000 km (36,000 miles)
Standard
Euro 5+
Co emissions
152 g/km
Consumption
6,6 l/100km
Notes
Only for countries where Euro 5+ standard applies. * Please check with your dealer product availability ** Only for countries where 4|ever Ducati warranty applies. Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
